DC-DC Step Up Converter Mini UPS Circuit 5V to 9V/12V Converter for ONU Routers, CCTV Cameras, and Mini UPS Systems

Specification:

• Battery : 1S Battery Connection
• Output Voltage: Adjustable to 9V or 12V DC
• Output Current: Maximum 2A
• Applications: ONT routers, CCTV cameras, LED lights, and other low-voltage devices
• Conversion Efficiency: Up to 95%
• Battery Compatibility: Supports external battery input (not included)
• Protection Features: Overcurrent, overvoltage, and short-circuit protection
• Material: High-quality PCB with durable components
• Weight: Approx. 20g
• Dimensions: 5 x 3 x 0.2 cm (L x W x H)

This module is a compact DC-DC step-up converter circuit designed to create a DIY mini UPS for devices like routers or CCTV cameras. It takes a 5V input to both power the output and charge a connected 3.7V lithium battery. When the main 5V power is lost, it automatically switches to the battery and boosts its voltage to a stable 9V or 12V output. It’s a simple board for ensuring your essential small devices remain powered during brief outages.
