Specification
Supported Battery Type: Li-ion / LiFePO4 / LTO
Cell Support: 8S to 24S Battery Pack
Charging Current: Up to 150A
Discharge Current: Up to 300A
Balancing Type: Active Balancer
Balancing Current: 0.6A
Communication: CAN Bus + RS485
Connectivity: Bluetooth + GPS Tracking System
Protection: Overcharge, Over-discharge, Overcurrent, Short Circuit, Temperature Protection
Monitoring: Real-time Voltage, Current, SOC, Temperature
Description
High-power smart BMS designed for large battery systems with up to 300A discharge capacity
Supports 8S–24S lithium battery packs including LiFePO4, Li-ion, and LTO
Built-in 0.6A active balancer ensures better cell balancing and longer battery life
Equipped with Bluetooth and GPS tracking for smart monitoring and location tracking
CAN and RS485 communication support for advanced system integration
Ideal for EV, solar storage, and industrial battery applications
Application
Electric vehicle (EV) battery systems
Solar energy storage solutions
High-power backup systems (IPS/UPS)
Industrial lithium battery packs
Smart battery monitoring with GPS tracking
