Input VoltageDC 12V (Operating Range: 8Vâ14.8V)
Output VoltagesSelectable 110V / 200V / 220V / 280V
Rated Output Power150W (Up to 200W Peak with Active Cooling)
Output WaveformHigh-Frequency Square Wave / Unfiltered DC
Operating Frequency~27kHz to 37kHz
No-Load CurrentApprox. 250mA at 12V DC Input
Voltage AdjustOnboard Jumper-Cap Switching
Wiring InterfaceHeavy-Duty Screw Terminal Blocks
Cooling MethodHeatsink (Fan Required >100W Load)
Circuit ProtectionsUnregulated (External Fuse Recommended)
